Huanyu Prefabricated Hole Layflat Hose for Drip Irrigation System
Huanyu Prefabricated Hole Layflat Hose for Drip Irrigation System
Prefabricated Hole Layflat Hose for Drip Irrigation System
Character:
Material:PE, new material
Usual size:75mm/80mm/90mm/110mm
Hole distance:40cm/60cm/90cm/customized
Protect the seedling from heat by innerside black outside white structure
Easy handling by prefabricated hole not manual drilling
All accessories couple with the main hose
Technical data:
Size | I.D | Working pressure | Burst Pressure | Weight | Meters/roll |
Inch | mm | bar | bar | Kg/m | m |
2 |
50 | 3 | 4 | 0.05 | 100 |
3.5 | 5 | 0.06 | 100 | ||
4.5 | 6.5 | 0.09 | 100 | ||
3 |
75 | 3 | 4 | 0.07 | 100 |
3.5 | 5 | 0.09 | 100 | ||
4.5 | 6.5 | 0.13 | 100 | ||
4 |
100 | 3 | 4 | 0.09 | 100 |
3.5 | 5 | 0.11 | 100 | ||
4.5 | 6.5 | 0.16 | 100 | ||
5 |
125 | 2.5 | 3.5 | 0.11 | 100 |
3 | 4 | 0.14 | 100 | ||
4 | 5.5 | 0.2 | 100 | ||
6 |
150 | 2.5 | 3.5 | 0.13 | 100 |
3 | 4 | 0.16 | 100 | ||
4 | 5.5 | 0.24 | 100 | ||
7 |
175 | 2 | 3 | 0.15 | 100 |
2.5 | 3.5 | 0.19 | 100 | ||
3 | 5 | 0.27 | 100 | ||
8 |
200 | 1.5 | 2.5 | 0.18 | 100 |
2 | 3 | 0.22 | 100 | ||
2.5 | 4 | 0.31 | 100 | ||
9 |
225 | 1.5 | 2.5 | 0.2 | 100 |
2 | 3 | 0.24 | 100 | ||
2.5 | 4 | 0.35 | 100 | ||
10 |
254 | 1.5 | 2.5 | 0.22 | 100 |
2 | 3 | 0.27 | 100 | ||
2.5 | 4 | 0.38 | 100 | ||
11 |
280 | 1.5 | 2.5 | 0.24 | 100 |
2 | 3 | 0.29 | 100 | ||
2.5 | 4 | 0.42 | 100 | ||
12 |
305 | 1.5 | 2.5 | 0.26 | 100 |
2 | 3 | 0.32 | 100 | ||
2.5 | 4 | 0.46 | 100 |
